Custom Aluminium Sheet Plate ASTM B209 5086 5083 H111 5356 5454
| Place of Origin | China |
|---|---|
| Brand Name | Sylaith |
| Certification | ISO 9001 |
| Model Number | 5052 5754 5083 |
| Minimum Order Quantity | 1 Ton |
| Price | Negotiable |
| Packaging Details | Standard seaworthy package |
| Delivery Time | 7-14 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 50000 Ton Per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Keyword | Aluminium Sheet Plate | Standard | GB/T3880 ASTM B209 |
|---|---|---|---|
| Processing Service | Bending, Decoiling, Welding, Punching, Cutting | Surface | Smooth |
| Temper | T3-T8, O, H12, H14, H16, H18, H22, H24, H26, H32, H112 | Width | 10mm ~ 2500mm |
| Highlight | 5086 aluminum plate,5083 aluminum plate,5356 aluminum plate |
||
Product Description
ASTM B209 Aluminium Alloy Plate 5083 H111 Aluminum Sheet Plate Per Square Meter
Product Description:
5083 belongs to al-Mg alloy, which is widely used, especially in the construction industry. It is the most promising alloy. Good corrosion resistance, good weldability, good cold processing, and has moderate strength. The main alloy element of 5083 is magnesium, which has good forming performance, corrosion resistance, weldability and medium strength. It is used for manufacturing aircraft fuel tank, oil pipe, as well as sheet metal parts of transportation vehicles and ships, instruments, street lamp supports and rivets, hardware products, electrical shell and so on.
| ASTM B209 Aluminium Alloy Plate 5083 H111 Aluminum Sheet Per Square Meter | |
| Alloy | 5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06 |
| Temper | O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc. |
| Specification | Thickness≤170mm; Width≤2200mm ; Length≤12000mm |
| Application | Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, Automobile Body Sheets, Automobile Inside Board, The Protective Cover On Engine. |
| Feature | All the advantages of normal aluminium alloy, high tensile strength & yield strength,good corrosion resistant performance, well welding property, well fatigue strength,and suitable for anodic oxidation. |
Product Details:
Product Use:
|
Material table
|
Product use
|
|
1000 series
(1050,1060,1100)
|
Food, chemical and extrusion coils, various hoses, fireworks powder
|
|
Chemical equipment is its typical use
|
|
|
Chemical products, food industry installations and storage containers, weldments, heat exchangers, printed boards, nameplates and reflective appliances
|
|
|
2000 series
(2024,2A12,2A14)
|
Aircraft structures, rivets, missile components, truck hubs, propeller components and other structural components
|
|
Aircraft skin, spacer frame, wing rib, wing beam, rivet, etc., and structural parts of buildings and transportation vehicles
|
|
|
Free forging and die forging with complex shape
|
|
|
3000 series
(3003,3004,3105)
|
Kitchen utensils, food and chemical products, storage equipment, storage tanks for transporting liquid products, and various pressure vessels and pipelines
|
|
Chemical product production and storage devices, plate processing parts, building processing parts, building tools and various lamp parts
|
|
|
Room partition, baffle, movable room board, eaves gutter and downpipe, sheet forming parts, bottle caps, corks, etc
|
|
|
4000 series
(4032,4043,4343)
|
Piston, cylinder head
|
|
Building distribution frame
|
|
|
The products are widely used in automobiles, water tanks, radiators, etc.
|
|
|
5000 series
(5052,5083,5754)
|
Aircraft fuel tank, oil pipe, traffic vehicle and ship sheet metal parts, instruments, street lamp supports and rivets, hardware products, etc
|
|
Plate Weldments of ships, automobiles and aircraft; Pressure vessel, refrigeration device, TV Tower, drilling equipment,transportation equipment
|
|
|
Storage tanks, pressure vessels, ship materials
|
|
|
6000 series
(6005,6061,6063)
|
Ladder, TV antenna, etc
|
|
Pipes, rods, profiles and plates for trucks, towers, ships, trams, furniture, mechanical parts, precision machining, etc
|
|
|
Building profiles, irrigation pipes and extruded materials for vehicles, stands, furniture, fences, etc
|
|
|
7000 series
(7075,7175,7475)
|
It is used for manufacturing aircraft structure and other high stress structural parts and molds with high strength and strong corrosion resistance
|
|
High strength structure for forging aircraft.
|
|
|
Aluminum clad and non aluminum clad plates for fuselage, wing frame, stringer, etc. Other parts with high strength and high fracture toughness
|
|
|
8000 series
(8011)
|
The aluminum plate with bottle cap as the main function is also used in radiators, most of which are used in aluminum foil products
|
Certification:
Packaging & Shipping:
FAQ:
Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
