Aluminum Steel Coil
Created with Pixso. 0.18mm Aluminium Strip Coil 5052-H32 1100-H14 8011/H22

0.18mm Aluminium Strip Coil 5052-H32 1100-H14 8011/H22

Brand Name: Sylaith
Model Number: 1100 1200 8011
MOQ: 1 Ton
Price: Negotiable
Delivery Time: 7-14 days
Payment Terms: L/C, T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
ISO 9001
Type:
Aluminum Coil
Thickness:
0.2-6.0mm
Inner Diameter:
75, 150, 200, 300, 505mm Etc.
Processing Service:
Bending, Decoiling, Welding, Punching, Cutting
Specification:
0.18mm X 105mm
Surface:
Emboss,mirror Plane,oxidation
Cutting Type:
Laser Cutting;Water-Jet Cutting;Flame Cutting
Model NO.:
1100 1200 8011
Packaging Details:
Standard seaworthy package
Supply Ability:
5000 Ton Per Year
Highlight:

1100-h14 Aluminum Coil

,

5052-h32 aluminum coil

,

0.18mm aluminium strip coil

Product Description

Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface



Product Description:



Aluminum has a series of more than any other non-ferrous metals, steel, plastic and wood more superior characteristics, such as such as the density is small, only 2.7 g/cm3, which is about 1/3 of the copper or steel;Good corrosion resistance and weatherability;Good plasticity and processing performance;Good thermal conductivity and electrical conductivity;Good low temperature resistance, high reflectivity and surface properties of light waves;Nonmagnetic;Basic non-toxic;Sound-absorbing sex;Good resistance to acid;Resistance to radiation performance is good;Elastic coefficient;Good mechanical properties;Excellent casting performance and welding performance;Good impact resistance.In addition, the high temperature properties of aluminum, formability, cutting machining, riveting and surface processing performance is good.



Product
Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface
Thickness(mm)
0.15mm-6.0mm / 6.0mm-25.0mm or as your requirements
Width(mm)
8mm-2000mm or as your requirements
Standard
GB, JIS, DIN, ASTM
Surface treatment
Mill, Brushed, Mirror, Embossed, Sandblasted, etc
Temper
O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38 H114/H194, etc.
Type
coil/sheet/strips/plate
Coil ID 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable
Coil OD 1700mm max.
Coil weight 1000-5000kgs
Package
Standard export package,such as wooden Pallet or as required.


Mechanical Property:



Alloy
Temper
Mechanical performance under room temperature
Tensile (Mpa) Elongation (e%) Erichson (IE,mm)
1100
1200
8011
O 80~110 ≥ 20 ≥ 6.0
H22 100~135 ≥ 16 ≥ 5.5
H24 115~145 ≥ 12 ≥ 5.0
H26 125~160 ≥ 8 ≥ 4.0
H18 ≥ 160 ≥ 1 -



No. Item Index Technique Index
1 Film Thickness 1.0~2.0 um (single side average thickness)

2

Hydrophile
Primary contact angle Primary contact angle ≤ 10°
Continuous contact Continuous contact ≤ 20°

3

Adherence
Erichson test (press deeply to 5mm): no peeling
Gridding test(100/100): no plunger separation
4 Corrosion Resistance R.N ≥ 9.5 Salt spray test (72 hours)
5 Alkali Resistance Dipped in 20% NaOH in 20 ºC for 3 minutes, absolutely no blister
6 Impregnant Resistance Samples weight loss 1%

7

Heat Resistance
Under 200 ºC, for 5 minutes, performance and colour unchanged
Under 300 ºC, for 5 minutes, the coating film becomes a little yellow
8 Oil proof Dip in volatile oil for 24 hours, no blisters on the coating film
9 Odor of the coating film No odor
10 Abrasion to mould Same as ordinary aluminium foil



Product Details:



0.18mm Aluminium Strip Coil 5052-H32 1100-H14  8011/H22 0



0.18mm Aluminium Strip Coil 5052-H32 1100-H14  8011/H22 1



Certification:



0.18mm Aluminium Strip Coil 5052-H32 1100-H14  8011/H22 2



Packaging & Shipping:



0.18mm Aluminium Strip Coil 5052-H32 1100-H14  8011/H22 3

0.18mm Aluminium Strip Coil 5052-H32 1100-H14  8011/H22 4



FAQ:



Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.

Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.

Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
