0.18mm Aluminium Strip Coil 5052-H32 1100-H14 8011/H22
| Place of Origin | China |
|---|---|
| Brand Name | Sylaith |
| Certification | ISO 9001 |
| Model Number | 1100 1200 8011 |
| Minimum Order Quantity | 1 Ton |
| Price | Negotiable |
| Packaging Details | Standard seaworthy package |
| Delivery Time | 7-14 days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5000 Ton Per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Aluminum Coil | Thickness | 0.2-6.0mm |
|---|---|---|---|
| Inner Diameter | 75, 150, 200, 300, 505mm Etc. | Processing Service | Bending, Decoiling, Welding, Punching, Cutting |
| Specification | 0.18mm X 105mm | Surface | Emboss,mirror Plane,oxidation |
| Cutting Type | Laser Cutting;Water-Jet Cutting;Flame Cutting | Model NO. | 1100 1200 8011 |
| Highlight | 1100-h14 Aluminum Coil,5052-h32 aluminum coil,0.18mm aluminium strip coil |
||
Product Description
Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface
Product Description:
Aluminum has a series of more than any other non-ferrous metals, steel, plastic and wood more superior characteristics, such as such as the density is small, only 2.7 g/cm3, which is about 1/3 of the copper or steel;Good corrosion resistance and weatherability;Good plasticity and processing performance;Good thermal conductivity and electrical conductivity;Good low temperature resistance, high reflectivity and surface properties of light waves;Nonmagnetic;Basic non-toxic;Sound-absorbing sex;Good resistance to acid;Resistance to radiation performance is good;Elastic coefficient;Good mechanical properties;Excellent casting performance and welding performance;Good impact resistance.In addition, the high temperature properties of aluminum, formability, cutting machining, riveting and surface processing performance is good.
|
Product
|
Variety 8011/H22 0.18mm Aluminum Steel Coil Different Size Alloy Coil With Variety Surface |
|
Thickness(mm)
|
0.15mm-6.0mm / 6.0mm-25.0mm or as your requirements
|
|
Width(mm)
|
8mm-2000mm or as your requirements
|
|
Standard
|
GB, JIS, DIN, ASTM
|
|
Surface treatment
|
Mill, Brushed, Mirror, Embossed, Sandblasted, etc
|
|
Temper
|
O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38 H114/H194, etc.
|
|
Type
|
coil/sheet/strips/plate
|
| Coil ID | 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable |
| Coil OD | 1700mm max. |
| Coil weight | 1000-5000kgs |
|
Package
|
Standard export package,such as wooden Pallet or as required.
|
Mechanical Property:
| Alloy | Temper |
Mechanical performance under room temperature | ||
| Tensile (Mpa) | Elongation (e%) | Erichson (IE,mm) | ||
| 1100 1200 8011 |
O | 80~110 | ≥ 20 | ≥ 6.0 |
| H22 | 100~135 | ≥ 16 | ≥ 5.5 | |
| H24 | 115~145 | ≥ 12 | ≥ 5.0 | |
| H26 | 125~160 | ≥ 8 | ≥ 4.0 | |
| H18 | ≥ 160 | ≥ 1 | - | |
| No. | Item Index | Technique Index | |
| 1 | Film Thickness | 1.0~2.0 um (single side average thickness) | |
2 |
Hydrophile |
Primary contact angle | Primary contact angle ≤ 10° |
| Continuous contact | Continuous contact ≤ 20° | ||
3 |
Adherence |
Erichson test (press deeply to 5mm): no peeling Gridding test(100/100): no plunger separation |
|
| 4 | Corrosion Resistance | R.N ≥ 9.5 Salt spray test (72 hours) | |
| 5 | Alkali Resistance | Dipped in 20% NaOH in 20 ºC for 3 minutes, absolutely no blister | |
| 6 | Impregnant Resistance | Samples weight loss 1% | |
7 |
Heat Resistance |
Under 200 ºC, for 5 minutes, performance and colour unchanged Under 300 ºC, for 5 minutes, the coating film becomes a little yellow |
|
| 8 | Oil proof | Dip in volatile oil for 24 hours, no blisters on the coating film | |
| 9 | Odor of the coating film | No odor | |
| 10 | Abrasion to mould | Same as ordinary aluminium foil | |
Product Details:
Certification:
Packaging & Shipping:
FAQ:
Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
