Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080

Place of Origin China
Brand Name Sylaith
Certification ISO 9001
Model Number 6000 Series
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Standard seaworthy package
Delivery Time 7-14 days
Payment Terms L/C, T/T, Western Union
Supply Ability 5000 Ton Per Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Aluminum Alloy Profile Grade 6000 Series
Surface Treatment Surface Treatment: Anodized, Powder Coating, Electrophoresis, Wooden-pattern Transfer... Tolerance ±1%
Alloy Or Not Is Alloy Deep Process CNC, Drilling, Milling, Cutting, Welding, Bending, Assembling
Application Door & Window Keyword Black Anodized Aluminum Profiles
High Light

Sylaith square aluminum profiles

,

aluminum profile angles Sylaith

,

Sylaith black anodized aluminum t slots

Leave a Message
Product Description

Angle T-Profile/Square Precise Cutting Aluminum Alloy Profile Anodized Alloy 6063 6061



Product Description:



Aluminium profiles are made using a high quality 6063 grade alloy with a T66 structural strength. A 12 micron coating ensures that any light scratches can be easily removed with an abrasive block, without affecting the colour of the anodising. Extrusions are easily connected together using the originial PCS connector system, for quick and efficient building.



Material aluminum alloy: 6061/6063/6005/6060 T3-T8
Shape according to drawing and sample (square, angle, flat, T-profile, rotundity, oval, slot)
Deep machining precise cutting, drilling, tapping, CNC milling, CNC lathe and so on.
Surface treatment polishing, anodized, electroplate, powder coating, sandblasting, painting…







product dimensions

1) 30 * 25 mm, suitable for 30-120 watts of solar components;

2) 35 * 35 mm, suitable for 80-180 watts of solar components;

3) 50 * 35 mm, suitable for 160-220 watts of solar components;

4) many other customized size, such as 17 * 17 mm, 20 * 20 mm, 23 * 17 mm, 25 * 25 mm * 25 mm, 35 * 30 mm, 40 * 28 mm, 40 * 30 mm, 40 * 35 mm, 42 * 35 mm and 45 * 35 mm, 46 * 30 mm, 46 * 35 mm, 48 mm *, 46 * 50 mm, 46 * 60 mm, 35 mm * 60, and so on.











Commonly used specifications

1956 * 992 * 50 mm

1650 * 992 * 45 mm

1640 * 992 * 45 mm

1580 * 808 * 40 mm

1576 * 808 * 40 mm

1482 * 670 * 40 mm

1200 * 545 * 35 mm

754 * 669 * 30 mm

824 * 545 * 30 mm

620 * 286 * 30 mm

540 * 342 * 25 mm

Other border length according to customer requirements production

Processing Two types

(1) 90°-Angle

(2)45° -Angle

Specifications According to your design drawings and your samples
Certification ISO9001-2008
Packaging Detail Export Standard Carton With Pallet, interleaving each profile to protect the surface
Delivery Detail Delivery time :10-15 days for tooling production & 15-20 days



Chemical Composition:



Alloy 6063(%) 6061(%) 6063A(%)
Si 0.2-0.6 0.4-0.8 0.3-0.6
Fe 0.25-0.35 0.65-0.72 0.18-0.25
Cu 0.1 0.2-0.38 0.15
Mn 0.1 0.15 0.15
Mg 0.45-0.8 0.8-1.2 0.6-0.9
Cr 0.1 0.04-0.3 0.05
Zn 0.1 0.25 0.15
Ti 0.1 0.15 0.1
Other(each) 0.06 0.06 0.06
Other(total) 0.15 0.15 0.15
Al Remainder Remainder Remainder



Product Details:

Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 0

Applicaion:



Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 1

Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 2



Certification:



Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 3



Packaging & Shipping:



Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 4

Square Aluminum Angle Profiles T Slot Cutting Anodized 2020 2040 4040 4080 5
