Brand Name: | Sylaith |
Model Number: | 6063 6061 6005 |
MOQ: | 1 Ton |
Price: | Negotiable |
Delivery Time: | 7-14 days |
6061-T5 L Shape Aluminum Angle Bar Customized 40x40 Extruded Aluminium Angle Profile
Product Description:
6063 aluminum plate. Building material, irrigation pipes and vehicle and bench for extrusion materials, furniture, fencing, etc.
6061 aluminum plate. Requires a certain intensity, high weldability and corrosion resistance of all kinds of industrial structural, such as manufacturing truck, tower building, vessel, trolley, furniture, machinery parts, such as precision machining with tube, rod, shaped material, plates.
6005 aluminum extrusion profiles and pipes, used for strong tall 6063 alloy structure, such as a ladder, TV antenna, etc.
Item | 6061-T5 L Shape Aluminum Angle Bar Customized 40x40 Extruded Aluminium Angle Profile |
Material | 6063,6060,6061,6005 |
Temper | T4,T5,T6 |
Surface treatment | Mill Finish,Anodized,Eletropharesis,Powder Coated, Wooden Finish, Polish |
Colour | Silver,Black,Red,Blue,White,and many other colors can be available |
Length | as required |
Shape | Flat,Round,Square,T-slot,or as per the drawings and samples |
Fabrication | cutting,drilling,punching,millling,etc |
Wall thickness | above 0.8mm |
Package | inner plastic paper interleaving each profile,outer fixed by plywood or pallets, or as per your requirements |
Payment terms | T/T or L/C at sight |
Certification | ISO 9001:2008;ISO14001:2004;SGS |
Application | Construction,Building,Projects |
Chemical Composition:
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rem |
6061 | 0.4-0.8 | 0.70 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rem |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.4-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rem |
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% |
Product Details:
Product Application:
Certification:
Packaging & Shipping:
FAQ:
Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
