2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA

  • 2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA
  • 2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA
Place of Origin China
Brand Name Sylaith
Certification ISO 9001
Model Number 2000 Series
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Standard seaworthy package
Delivery Time 7-14 days
Supply Ability 50000 Ton Per Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Grade 2000 Series Standard ASTM AISI JIS DIN GB
Material Aluminun Alloy Hardness ≥120HB
Length 100mm - 6000mm Temper T3 - T8
Processing Service Bending, Decoiling, Welding, Punching, Cutting Surface Treatment Mill Finish
Al (Min) 90.7% Ultimate Strength (≥ MPa) 430
High Light

2219 aluminum round bar

,

2618 aluminum round bar

,

aircraft grade aluminum bar
Leave a Message
Product Description

100mm-6000mm Length 2024AA Round Bar Alloy Solid Aluminum Bar For Aircraft Structure



Product Description:

2000 series aluminum rods represent 2A16 (LY16), 2A02 (LY6). 2000 series aluminum bar is characterized by high hardness, with the highest content of copper element, about 3-5%. 2000 series aluminum rod belongs to aviation aluminum material, which is seldom used in conventional industry.2024 is a typical duralumin alloy in the aluminum-copper-magnesium system. It is a heat-treatable alloy with high strength, easy to work, easy to turn, and moderate corrosion resistance.

After heat treatment (T3, T4, T351), the mechanical properties of 2024 aluminum bar are significantly improved. Its T3 state parameters are as follows: tensile strength 470MPa, 0.2% yield strength 325MPa, elongation 10%, fatigue strength 105MPa, hardness 120HB.

Main applications: aircraft structure, rivets, truck wheels, propeller components and other structural parts.



Model Number
7050 7075 6061 6063 6082 5083 2024
Application
Auto Part/Industrial/Machinery equipment
Surface Treatment
Mill Finish
Shape
Round
Technique
Cold Drawn
Grade
2000 Series
Hardness
T6 T12 T24
Alloy Or Not
Non-Alloy
Al (Min)
90-99.9%
Yield (≥ MPa)
375
Temper
T3 - T8
Tolerance
±1%
Processing Service
Bending, Decoiling, Welding, Punching, Cutting
Delivery Time
8-14 days
Product name
Aluminum Alloy Rod
Material
2000series/3000series/4000series/5000series/6000series/7000series
Type
Round Shape
MOQ
1 Ton
Item
Aluminum Round Bar 6061 T6
Surface
Mill Finish Polished
Length
0-6000mm
Standard
ASTM AISI JIS DIN GB


Mechanical Property:



                                                              Mechanical Property
ALUMINUM
ALLOY		 Grade Normal
Temper		 Temper Tensile Strength
N/mm²		 Yield Strength
N/mm²		 Elongation% Brinell Hardness
HB
Plate Bar
1XXX 1050 O,H112,H O 78 34 40 - 20
1060 O,H112,H O 70 30 43 - 19
Al-Cu
(2XXX)		 2019 O,T3,T4,T6,T8 T851 450 350 10 - -
2024 O,T4 T4 470 325 20 17 120
Al-Mn
(3XXX)		 3003 O,H112,H O 110 40 30 37 28
3004 O,H112,H O 180 70 20 22 45
Al-Si (4XXX) 4032 O,T6,T62 T6 380 315 - 9 120
Al-Mg
(5XXX)		 5052 O,H112,H H34 260 215 10 12 68
5083 O,H112,H O 290 145 - 20 -
Al-Mg-Si
(6XXX)		 6061 O,T4,T6,T8 T6 310 275 12 15 95
6063 O,T1,T5,T6,T8 T5 185 145 12 - 60
Al-Zn-Mg
(7XXX)		 7003 T5 T5 315 255 15 - 85
7075 O,T6 T6 570 505 11 9 150


Product Details:


2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 0

2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 1



Product Application:



2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 2



Certification:



2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 3





Packaging & Shipping:



2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 4

2219 2618 3003 Aluminum Round Bar Aircraft Grade 100mm-6000mm 2024AA 5



FAQ:



Q1: ARE YOU FACTORY OR TRADER?
A1: Sylaith Special Steel is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.

Q2: HOW TO GET A SAMPLE?
A2: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.

Q3: HOW TO VISIT YOUR FACTORY?
A3: Most of the main cities have flights to Shanghai; you can take flight to Shanghai Putong/Hongqiao International Airport.
If you come from Hongkong, it will take 2 hours by flight (every day 5 flight around noon time).
